QXi

2.97mm to 3.91mm pixel pitches

Indoor Variable pitch

The Atenti Global QXi Series is an indoor LED display solution designed for the rental and staging market, offering a cost-effective alternative to our elite series. While maintaining the same core specifications, the QXi Series features a different cabinet construction. Engineered for ease of use in temporary installations, the QXi Series prioritizes efficient setup and dismantling. Like our elite rental options, the QXi series can also create curved displays using faceted cabinets.

  • Budget-Friendly Rental Solution: A cost-effective option for indoor rental and staging applications.
  • Efficient Setup and Dismantling: Designed for ease of use, ensuring quick assembly and disassembly at events.
  • Durable Cabinet Construction: Focuses on a practical cabinet construction.
  • Creative Flexibility: Faceted cabinet options allow for the creation of curved displays.
2.97mm 3.91mm
Download brochure

Speak to us about this product

For more information about this product or any Atenti Global products please speak to us.

Speak to us

Module

  • Parameter
  • Specification
  • Pixel Pitch (mm)
  • 3.91mm
  • LED type
  • 1R1G1B
  • Packet type
  • 2020
  • LED Package Technology
  • SMD
  • PCB Layers
  • 4
  • Bonding
  • Copper
  • Pixel density (m2)
  • 65536
  • Module Resolution
  • 64 x 64
  • Module size (Wmm x Hmm)
  • 250 x 250

Cabinet

  • Parameter
  • Specification
  • Cabinet Materials
  • Aluminium
  • Cabinet Dimensions (mm)
  • 500 x 500 x 90
  • Cabinet Resolution
  • 128 x 128
  • Cabinet Weight (Kg)
  • 8
  • Service Access
  • Both
  • IP Rating
  • 31/43

Operation & certification

  • Parameter
  • Specification
  • Max power
  • 600
  • AVE power
  • 200
  • Heat dissipation max
  • 1884
  • Heat dissipation AVE
  • 628
  • Power supply
  • AC 86-264V
  • Operating temp/humidity
  • 0°C - + 55°C / 10%-90%RH
  • Storage temp/humidity
  • -20°C - + 60°C / 10%-90%RH
  • Lifetime (hours)
  • 100000
  • Certifications
  • CE, UL, BIS, ROHS, ISO9001:2015


  • Parameter
  • Specification
  • Brightness
  • 1200
  • Contrast ratio
  • 8000:1
  • Bit depth
  • 14
  • Viewing angle
  • 160 x 160

Device drivers

  • Parameter
  • Specification
  • IC controller
  • ICN2153
  • Drive method
  • 1/16
  • Refresh rate
  • 3840
  • Supported frame rate
  • 50-60
Broadcast (outside broadcast)

Deliver crystal-clear visuals for outside broadcasts and set designs, ensuring seamless content delivery and professional presentation with high-resolution LED technology.

Stadium (outside broadcast)

Deliver thrilling experiences with high-impact LED scoreboards, perimeter displays, and spectaculars, enhancing fan engagement and event atmosphere.
