QXo

QXo

2.97mm to 4.81mm pixel pitches

Outdoor Variable pitch

The Atenti Global QXo Series is an outdoor LED display solution tailored for the rental and staging market, providing a cost-effective alternative to our elite series. While maintaining the same core performance specifications, the QXo Series features a different cabinet construction optimized for outdoor use. Engineered for ease of use in temporary outdoor installations, the QXo Series prioritizes efficient setup and dismantling while ensuring reliable performance. Similar to our elite rental options, the QXo series can also create curved displays using faceted cabinets.

  • Budget-Friendly Rental Solution: A cost-effective option for outdoor rental and staging applications.
  • Efficient Setup and Dismantling: Designed for ease of use, ensuring quick assembly and disassembly at outdoor events.
  • Durable Cabinet Construction: Features a practical cabinet construction optimized for outdoor use.
  • Creative Flexibility: Faceted cabinet options allow for the creation of curved displays, expanding design possibilities for outdoor productions.
2.97mm 3.91mm 4.81mm

Speak to us about this product

For more information about this product or any Atenti Global products please speak to us.

Module

  • Parameter
  • Specification
  • Pixel Pitch (mm)
  • 2.97mm
  • LED type
  • 1R1G1B
  • Packet type
  • 2020
  • LED Package Technology
  • SMD
  • PCB Layers
  • 4
  • Bonding
  • Copper
  • Pixel density (m2)
  • 112896
  • Module Resolution
  • 84 x 84
  • Module size (Wmm x Hmm)
  • 250 x 250

Cabinet

  • Parameter
  • Specification
  • Cabinet Materials
  • Aluminium
  • Cabinet Dimensions (mm)
  • 500 x 500 x 90
  • Cabinet Resolution
  • 168 x 168
  • Cabinet Weight (Kg)
  • 8
  • Service Access
  • Both
  • IP Rating
  • 65

Operation & certification

  • Parameter
  • Specification
  • Max power
  • 750
  • AVE power
  • 250
  • Heat dissipation max
  • 2355
  • Heat dissipation AVE
  • 785
  • Power supply
  • AC 86-264V
  • Operating temp/humidity
  • 0°C - + 55°C / 10%-90%RH
  • Storage temp/humidity
  • -20°C - + 60°C / 10%-90%RH
  • Lifetime (hours)
  • 100000
  • Certifications
  • CE, UL, BIS, ROHS, ISO9001:2015


  • Parameter
  • Specification
  • Brightness
  • 5000
  • Contrast ratio
  • 5000:1
  • Bit depth
  • 14
  • Viewing angle
  • 160 x 160

Device drivers

  • Parameter
  • Specification
  • IC controller
  • ICN2153
  • Drive method
  • 1/16
  • Refresh rate
  • 3840
  • Supported frame rate
  • 50-60
Broadcast (outside broadcast)

Deliver crystal-clear visuals for outside broadcasts and set designs, ensuring seamless content delivery and professional presentation with high-resolution LED technology.

Stadium (outside broadcast)

Deliver thrilling experiences with high-impact LED scoreboards, perimeter displays, and spectaculars, enhancing fan engagement and event atmosphere.
